Boiler & Special Product

Description

  1. Safety & Pressure Reducing Valves;
    • Safety Valve, Safety Relief Valve, Relief Valve
    • Pressure / Vacuum Valve
    • Conventional Type Design
    • Pilot Operated Type Design
    • Block Body , Rupture Disc
    • ASME Section VIII, Div. I for Unfired Pressure Vessels
    • API 2000 : Venting Atmospheric and Low-Pressure Storage  Tanks  ( API 2521 - use of Pressure vacuum vent Valves )
    • Low Pressure and High Pressure ( 150, 300, 600, 800, 900, 1500, 2500 )
    • Material: Brass, Bronze, Cast Steel, Stainless Steel other Requirement
    • Standard Design  ANSI, DIN, BS, JIS
    • Size 1/4” – 12”
  2. Color Port Gauge and Sigh Glass;-
    • Color Port (red/Green), Flat Glass (illuminated) and Reflex & Tubular
    • Electric : Aquarian Single Point Level Switch
    • Material: Cast Steel, Stainless Steel other Requirement
    • Low Pressure and High Pressure ( 150, 300, 600, 1500, 2500 )
    • Standard Design  ANSI, DIN, BS, JIS
    • Size 1/2” – 1.1/2”
  3. Steam Trap;-
    • Standard Type  Mechanical, Thermostatic, Thermodynamic Design
    • Material: Cast Steel, Stainless Steel other Requirement
    • Low Pressure and High Pressure ( 150, 300, 600, 1500 )
    • Standard Design  ANSI, DIN, BS, JIS
    • Size 1/4” – 6”
  4. De-Super Heater;-
    • Conventional System, Integral Design
    • Material: Cast Steel, Stainless Steel other Requirement
    • Low Pressure and High Pressure ( 150, 300, 600, 1500, 2500 )
    • Standard Design  ANSI, DIN, BS, JIS
  5. Diaphragm, Ball and Butterfly Valves;-
    • Material: Cast Iron, PVC, UPVC, Terence or other Requirement.
    • Low Pressure and High Pressure ( 150 )
    • Standard Design  ANSI, DIN, BS, JIS
    • Ends Connection Flange, Screwed
    • Operation Hand wheel, Gear Box, Automation
    • Size ¼” – 24”
  6. Knife Gate Valves;
    • Material: Cast Iron, Cast Steel, Low Carbon Steel, Stainless Steel, Alloy and Other Requirement.
    • Standard Design  ANSI, DIN, JIS
    • Ends Connection Flange.
    • Operation Hand wheel, Gear Box, Automation
    • Size 2” – 24” or other Requirement.
    • Knife Gate Valves are available in sizes 2" - 48" (50 mm - 1200 mm) and in a range of body & seat materials we offer a variety of actuator options including rising stem & non-rising stem hand wheel, pneumatic cylinder, levers, bevel gearbox, chain wheels & electric motors. A full complement of accessories including deflection cones and purge points are also available
    • ETM Gate Valves are primarily designed to start or stop flow, and when a straight-line flow of fluid and minimum flow restriction are needed. In service, these Valves generally are either fully open or fully closed.The wedge of a Gate Valve is completely removed when the Valve is fully open; the wedge is fully drawn up into the Valve Bonnet. This leaves an opening for flow through the Valve at the same inside diameter as the pipesystem in which the Valve is installed. The gate valve can be used for a wide range of Steam, gases, liquids,Oil etc.
  7. Rupture Discs;

    Oseco’s HPSR (High Pressure Scored Reverse) buckling rupture disc assembly is designed and manufactured for demanding high pressure gas and liquid applications. Its welded design eliminates leak paths and allows for easy installation.

    • Size Range: 1"- 24" DN25-DN 600
    • Service Type: Gas & Liquid
    • Operating Ratio: 95%
    • Size Range: 1"-10" DN25-DN 250
    • Service Type: Gas and Liquid
    • Operating Ratio: 95%
  8. Rack & Actuators;

    - MT Series Aluminum  MT Series rack & pinion pneumatic actuators continue the Max-Air tradition of easy integration, flexible customization, and reliable operation. Features include two ISO bolt circle patterns drilled directly in the body, NAMUR standard mounting for accessories, and our patented ±10° adjustment for the open/closed positions, all backed by the best unlimited cycle life warranty.

    - UT Series Flanged Aluminum / The UT Series rack & pinion actuators are the original Max-Air innovation featuring a removable flange for easy valve integration, flexible customization, and reliable operation. The UT Series has all the same great features of the MT Series, including NAMUR standard mounting for accessories, and our patented ±10° adjustment for both the open and closed positions, all backed by the best unlimited cycle life warranty.

    - Actuators  The new technical features developed and incorporated in this product line allow to have the best product versatility for an easier valve automation.  The design in fully compliance with all the international standards is also covered by international patents. The 4th Generation Upgrade series offers the widest and most complete actuator range with huge options availability.

    The 4th Generation Upgrade line counts a combination of:

    • 17 different model sizes both in double acting and spring return
    • 6 different protection levels
    • 3 different working temperature executions (from -55°C/-67°F up to +150°C/+302°F)
    • Multiple choice of ISO flange and drive shaft connection for each actuator size.

  9. Y-Strainer;

    ETM Y Strainer is Europe type screen,with plug design. This product is designed for remove foreign matter from pipe lines and provides protection for pumps, meters, valves, and other similar mechanical equipment, which is called as Strainer. "Y" Type Strainers are named after their shape and normally used for course filtration. But with large filtration area can be used with fine mesh also. The Strainer improves the clearance in the medium, and prolongs the life of valves; protect expensive pumps, meters and other equipments. It is suitable for water, Air, Gas, petroleum, steam and other fluids.
